Model: SATA04
Features:
1. Onboard Ruixin Micro RK3566/3568/RK3588.
2. Support 4G/5G Internet access function, meet the communication requirements (need to add a separate module).
3. Supports WIFI and Bluetooth.
4. GPS, CAN communication module (need separate module).
5. Aluminum-magnesium alloy heat dissipation cover, Conduction heat dissipation.
6. DC12V power input.
7. Compatible with Android, Linux.
Our Embedded Mini PC Computer series offers a wide range of options. We offer a wide range of affordable industrial mini PCs, and we are a full-service industrial computer supplier.
Fully functional, customizable mini PCs can be used as embedded computers or industrial computers, digital signage solutions, digital kiosks, video conferencing or edge computers and remote management, making you as powerful as a professional.
Embedded PCs are miniature, high-tech, multi-functional computers. These computers are designed to build compact embedded and mobile systems in limited workspace environments and with specific size and weight requirements.
SATA offers a full range of fanless industrial embedded computers for a variety of applications. For affordable and rugged computing power in a compact package, ideal for edge computing, machine vision and other processor-intensive applications.
We provide ODM/OEM services. If you have any questions about the Embedded Mini PC Computer, please contact us!
| PC | |
| CPU | RK3566 Cortex-A55, Quad Core, 1.8GHz |
| CPU Optional | RK3568 Cortex-A55, Quad Core, 2.0GHz |
| CPU Optional | RK3588 Quad Cortex-A76+Quad Cortex-A55, 2.1GHz |
| Memory | 2G/4G/8G |
| Storage | 16G/32G/64G |
| Display Chip | Integrated Intel HD Graphics card |
| Network | 2xRealtek 8111E LAN, support wake on LAN(Linux) |
| Audio | Integrated Realtek ALC662 6 sound channel |
| I/O Interface | 1x USB 3.0, 3x USB 2.0, 4xRS232 COM, 2xRJ45 LAN, 1xHDMI, 1x MIC/SPK/SD Card slot/SIM Card slot/Phoenix terminal 12V port, 1x Power switch |
| Operation System | Support Android, Linux |
| Power Supply | |
| External Power Supply | AC 100-240V |
| Working voltage | DC 12V |
| Power consumption | ≤40W |
| Enclosure | |
| Material | Aluminum Alloy |
| Color | Black+Silver Grey |
| Operating Environment | |
| Temperature Range | Operating: -10 to 60°C, storage: -30 to 80°C |
| Relative humidity | 10%~95%@40°C, non-condensing |
| Packing Details | |
| Net weight | 2kgs |
| Gross weight | 3kgs |
| Product Dimension | 21.3*13.8*3.8cm |
| Packing size | 41*23*11cm; Big Carton size: 43*25*46cm, 12kgs 4pcs/ctn |
| Accessories | Power adapter, VESA brackets, screws, user manual, warranty card |
| Other | |
| Mounting (options) | VESA brackets (free) |
| Open frame mounting (Optional) | |
| Warranty | 1 years warranty |
