Model: SATA05MW
Features:
1. Robust and durable Aluminum alloy bezel and metal back case, full IP65 waterproof.
2. Industrial grade LCD panel, high brightness 1000nits, sunlight readable
3. Adopt high precision industrial 4 wires resistive touch screen,high precision, durable, anti-interference.
4. High performance mainboard, 7x24 continuous operation.
5. Support wide voltage: 12-24V DC input .
6. With waterproof speaker on the back case.
7. With button on the bezel,to adjust the brightness.
| LCD panel | |
| Panel size | 5" |
| Resolution | 800*480 |
| Aspect ratio | 15:9 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 1000 nits, sunlight readable |
| Contrast ratio | 600:1 |
| View angle | 75°/75°/60°/70° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | 4-wire Resistive touch |
| Touch Interface | USB (RS232 Optional) |
| Touch response time | <8ms |
| Luminousness | 75-85% |
| Surface Hardness | 3H |
| Working Life | >35 million times |
| Touch options | (PCAP touch Optional) |
| Singal Ports | |
| VGA | Optional |
| HDMI | 1×HDMI |
| DVI | Optional |
| AV | Optional |
| Audio in/out | Optional |
| OSD | |
| OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
| Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc. |
| Support OS | Windows XP, Windows 7/8/10, Linux, Mac OS X, Android and etc. |
| Power Supply | |
| External Power Supply | AC 100-240V |
| Working voltage | DC 12V-24V wide voltage |
| Power consumption | 10W |
| Enclosure | |
| Material | Aluminum alloy bezel+High strength cold rolled steel back case |
| Color | Black, Silver, White (Color can customize) |
| VESA mounting | 75×75mm |
| IP-grade | Full IP65 |
| Operating Environment | |
| Temperature Range | Operating: -20 to 70°C, storage :-30 to 80°C |
| Relative humidity | Operating: 10% to 90%, storage: 5% to 90% |
| Packing Details | |
| Net weight | 1.1kgs |
| Gross weight | 1.8kgs |
| Product Dimension | 16.2×11.6×3.6 cm |
| Packing size | 33.0×21.6×8.7 cm |
| Accessories | Power adapter, touch pen, touch driver, keyboard pad, user manual, warranty card |
| Other | |
| Mounting (options) | 1) Provide wall brackets for wall-mounting, VESA 75×75mm |
| 2) Provide stable metal holder to support the monitor | |
| Warranty | 1 year |
