21.5" full view IP65/IP67 Optional touch panel PC for boat navigation

Model: SATA215XW

Features:

1. Made of sturdy and durable aluminum Alloy front bezel+High strength cold rolled steel back case.

2. Industrial  LCD panel, wide viewing angle, high nits, true color.

3. Fully sealed and fanless design, full IP65 waterproof, Sealed I/O with cable set included.

4. Adopt 5 wire resistive touch screen, high precision, durable, anti-interference.

5. High performance motherboard, fanless design, 7x24 continuous operation.


PC
CPUIntel® Celeron J1900, quad core, 2.0GHz, fanless
ChipsetIntel ValleyView SSA-CUnit
Memory4G DDR3 (8G Optional)
Hard Drive Capacity64G SSD
Hard Drive OptionalSSD: 128GB, 256GB, 512GB, 1TB, 2TB
HDD: 500GB, 1TB
GraphicsCPU Integrated graphics HD Graphics and support 1080p HD photo quality
AudioRealtek ALC662, High Definition Audio (HD), Line in, Line out
Network1xRealtek RTL 8111E Gigabit Ethernet controller
Wireless NetworkWIFI Optional
I/O Interface2xUSB 2.0, 3xCOM RS232, 2xRJ45
1xVGA/HDMI/POWER DC
Operation SystemSupport Windows 7/8/10, Linux, Ubuntu, Debian, etc.
LCD panel
Panel size21.5"
Resolution1920*1080
Aspect ratio16:9
Support Color16.7M colors
Brightness (cd/m²)300 (1000 nits sunlight readable Optional)
Response time5ms
Contrast ratio1000:1
View angle89°/89°/89°/89° (R/L/U/D)
Touch panel
Touchscreen Type5 wires resistive touch
Touch InterfaceUSB (RS232 Optional)
Touch response time<8ms
Luminousness90%
Surface Hardness3H
Working Life >35 million times
Touch options(Capacitive touch Optional)
Power Supply
External Power SupplyAC 100-240V
Working voltageDC 9V-24V wide voltage
Power consumption≤50W
Enclosure
MaterialAluminum Alloy front bezel+High strength cold rolled steel back case
ColorSilver, Black, White, color can customize
VESA mounting100x100mm
IP gradeFull IP65 waterproof
Operating Environment
Temperature RangeOperating: -20 to 70°C, storage: -20 to 80°C
Relative humidity5%~95% @ 40° C, non-condensing
Vibration5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Packing Details
Net weight11kgs
Gross weight12.6 kgs
Product Dimension54.5x34.6x5.7cm
Packing size68x48x21cm
AccessoriesPower adapter, waterproof VGA/HDMI/RS232/LAN/USB cable/Power cord, Wall mount
Other
MountingWall mounting brackets
Desk stand holder (Optional)
Warranty1 year warranty
CertificateCE, FCC, RoHS
